Nanjing Makas Carbide Knives Co.,Ltd. produce Zund Z20 Blade,Zund Z20,Zund Blade,Zund,zund 3910313,zund 3910313 Blade, Zund Z20 oscillating blade, Zund Z20 drag blade.

TC knife blade Z 20

cutting depth approx. 14,3 mm
no. 3910313

suitable for machine manufacturer: original blade no.

CombiPro

Dyss

Esko Kongsberg: ( G42421974, 42421974, BLD-SF420, (i-420) )

iEcho

Mécanuméric

Summa: ( 500-0811, 500-9811 )

Zünd: 3910313, Z20

recommended materials:

Corrugated, Corrugated plastic, Corrugated sandwich, sandwich panel, Foam board, Folding Carton, Magnetic foil, Polyester fabric, Rubber, Felt, Foam

Zund Blade Z20 HTZ-20 compatible knife for Zünd automated cutting machine
Description: Very fine, delicate blade with minimal overcut; designed to cut small radii and intricate detail.

Thickness: 0,63 mm.

Tools: EOT and POT.

Composition: HM - Hard Metal.

Materials: Corrugated cardboard: B, C, BC, EB and E flute, Folding carton: 100 - 1500 g, Light foam core, Foam, Ejection rubber and Felt.

Compatible Brand
Zund
Equivalent
Z20
Thickness
0.63 mm.
Max. cutting depth
13,3 mm
Pre-cut
1.2 + 0.11 x Tm
Post-cut
-
Composition
HM - Metal Duro
Tool
POT / EOT
Recommended materials
Corrugated
Corrugated plastic
Felt
Foam
Foam board / Foam
Folding carton
Hard foam
Magnetic material
Polyester fabric
Rubber
Sandwich board
Associated brands of raw materials
Airplac Foamboards
Egafix
Espanso Cartonato
Foam-X
Forex
Gatorfoam
Kapamount

Item no.

3910313

Knife type

Oscillating blade pointed

Properties

Very fine, delicate blade with minimal overcut; designed to cut small radii and intricate detail.

Recommended materials

Corrugated

Corrugated plastic

Sandwich board

Foam board/Foam

Folding Carton

Magnetic foil

Polyester fabric

Rubber

Felt

Pre-cut

1.2 + 0.11 x TM

Post-cut

Max. cutting depth

14.3 mm

Knife thickness

0.63 mm

Knife material HM/Carbide

Zund Blades Z10(3910301), Zund Blades Z11(3910309),Zund Blades Z12,Zund Blades Z13,Zund Blades Z16(3910306), Zund Blades Z17(3910307),Zund Blades Z20(3910313),Zund Blades Z21(3910314),Zund Blades Z22(3910315), Zund Blades Z23(5005560),Zund Blades 26(3910317), Zund Blades Z28(3910318),Zund BladesZ29(3910319),Zund Blades Z30(3910330),Zund BladesZ31(3910331),Zund Blades Z33(3910333), Zund Blades Z34(3910334),Zund Blades Z35(4800071), Zund Blades Z41(3910323),Zund Blades Z42(3910324), Zund Blades Z42C(5203005),Zund Blades Z43(3910325), Zund Blades Z44(3910340), Zund Blades Z46(4800073), Zund Blades Z50(3910335),Zund Blades Z51(3910336), Zund Blades Z52(3910337),Zund Blades Z53, Zund Blades Z55,Zund Blades Z60(5201345), Zund Blades Z61(5201343), Zund Blades Z62(5002488), Zund Blades Z63(5002637), Zund Blades Z64(5002739), Zund Blades Z66(5200479), Zund Blades Z68(5204301), Zund Blades Z69(5204302), Zund Blades Z70(5005642),Zund Blades Z71(5006045), Zund Blades Z73, Zund Blades Z82, Zund Blades Z83

Zund Z20 Blades Tungsten Carbide Knives and Blades
